ADXL335 Module 3-axis Analog Output Accelerometer

The ADXL335 is a small, thin, low-power, complete 3-axis accelerometer with signal conditioned voltage outputs. The ADXL335 Module 3-axis Analog Output Accelerometer measures acceleration with a minimum full-scale range of ±3 g.

\n

It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration. This breakout board comes with an onboard voltage regulator and works at both 3.3V & 5V (3-5V).

\n

An accelerometer is an electro-mechanical device that will measure acceleration forces. These forces may be static, like the constant force of gravity pulling at your feet, or they could be dynamic – caused by moving or vibrating the accelerometer.

\n

Applications :

\n

1. \n
2. FPV, RC, and Robots systems
3. \n
4. GPS navigation systems
5. \n
6. Impact recognition and logging
7. \n
8. Gaming and virtual reality input devices
9. \n
10. Motion-activated functions
11. \n
12. Intelligent power saving for handheld devices
13. \n
14. Vibration monitoring and compensation
15. \n
16. Free-fall detection
17. \n
18. 6D-orientation detection
19. \n

\n

\n

Features :

\n

1. \n
2. Onboard LDO Voltage regulator
3. \n
4. Can be interfaced with a 3V3 or 5V Microcontroller.
5. \n
6. All necessary Components are populated.
7. \n
8. Ultra-Low Power: 40uA in measurement mode, 0.1uA in standby@ 2.5V
9. \n
10. Tap/Double Tap Detection
11. \n
12. Free-Fall Detection
13. \n
14. Analog output
15. \n
16. Build-in ultra-low noise linear LDO voltage regulator
17. \n
18. Built-in onboard filters, which reduce noise from the motor and other high current electronics
19. \n
20. Power LED
21. \n
22. Designed for 5V logic level
23. \n

\n

\n

Package Includes :

\n

1 X ADXL335  3-axis Analog Output Accelerometer Module
